Titan® Air Cooled Heat Pump

Our Titan Series Heat Pumps are the Big Daddy of heat pumps, utilizing our indestructible titanium coil or tube sheet design for maximum heat transfer efficiency. Designed for use in a wide variety of both saltwater and freshwater applications, our Titan Series are a favorite among public aquariums, zoos, government hatcheries, hydroponic and aquatic research facilities. With lives in the balance, why take a risk? Aqua Logic’s Titan heat pump is the versatile, reliable, and logical choice.

Titan Heat Pumps by Aqua Logic are designed for a wide range of commercial duty applications.  All Titan Heat Pumps feature an insulated titanium heat exchanger and a commercial TRANE condensing unit, mounted together on a stainless steel frame. Suitable for outdoor installation and guaranteed to reliably deliver stable temperature control in the range of 40-85ºF.

System Requirements:

Titan Heat Pumps require a pump to move water through the heat exchanger at all times.

• Please adhere to minimum and maximum flow rates provided by Aqua Logic.
• Always use an external pump as submersible pumps add heat to the water.
• Condenser requires air flow and must not be installed in a confined space.
• In Heating Mode cool air is discharged from the condenser and condensation may drip from the unit so it is recommended that the units be placed in a drip pan.

Not available for sale in online store. Please contact us for assistance with sizing and purchase.

• Features
• Sizing
• Specifications
• Options
• Product Literature
• Product Inquiry
• 1 1/2 Hp – 20 Hp
• Heat or Chill with one unit
• Insulated Titanium Heat Exchanger
• TRANE Condensing Unit
• Dual Stage Digital Temperature Controller in NEMA4X enclosure
• Built in Safety Flow Switch
• Includes stainless steel stand
• Fresh or Saltwater use
• All units suitable for outdoor use

Titan Heat Pumps up to 5hp have a specialized spiral condenser coil which has proven to have superior heat transfer performance and capacity over conventional radially finned condenser coils, and has a much greater resistance to corrosion in harsh environments.

For Cooler Climates: If ambient air temperatures can fall below 55ºF when operating unit in cooling mode, then low ambient controls must be installed on the condensing unit. This will allow the unit to operate in cooling mode in air temperatures down to 0ºF.

When exposed to colder air temperatures ice may form on the condenser in which case the unit will automatically go into defrost mode based on a preset time interval.

In Heating Mode the heat pump will lose efficiency with air temps below 45ºF and it is recommended that you switch to electric or gas heat. Please consult Aqua Logic if you expect temperatures below 45oF. Precautions must be taken to ensure water flow is not interrupted to unit during freezing conditions to prevent exposed outdoor water lines and heat exchanger from freezing. If unit will not be in use during freezing conditions the outdoor plumbing and heat exchanger should be completely drained of water.

The following options are available on request:

• Powder coating available for Stainless Steel stand at an added charge.
• Coastal coating protection available for condensing units that may be exposed to salt air or corrosive environment. Additional charge will be incurred.
• Stainless steel stand can be upgraded to 316SS  for an additional charge.
