45206.104

SYSTEM PUMPS

Industrial Grade, energy efficient pump solutions.

RK2 Systems pumps are a high efficiency, industrial grade pump. Ideal for your aquaculture, public aquaria or general transfer and recirculation needs - RK2 Systems pumps produce excellent flow rates at sufficient pressure (head) to really get the job done. The industrial grade noryl housings are built for long term use. Patented motor shaft seal design provides superior corrosion resistance by protecting metal components by contained fluid in the wet end of the pump and from surrounding environment. A strainer pot may be attached to facilitate priming in a suction lift application and to strain debris from the inflow.

RK2 Systems pump features include:

Industrial duty non-corrosive construction
Outstanding flow to amp design
Highest quality motors made in the U.S.A.
Impenetra Motor Shaft Seals featuring Carbon Graphite Head, Viton® Trim, Ceramic Mating Ring, Polypropylene Case
PVC encapsulated stainless steel shaft
316 stainless steel hardware
1/8HP - 3HP models
Low heat transfer, extremely quiet and energy efficient
TEFC standard enclosures on all models
50Hz and many voltage configurations available
Option to choose single phase or three phase motors

Design

All RK2 Systems pumps are molded out of high-quality glass-filled Noryl®, which gives it many advantages. It is completely saltwater resistant, has excellent tensile strength, very low water absorption, and a continuous temperature rating of 194° F. Engineered for high efficiency, our enclosed impellers will accommodate a wide variety of flow rates and pressure requirements.

115/230VAC 60Hz. Single Phase Pumps

Best Efficiency Point Operation

25 GPM Flow Rate
15.2 FT Head Pressure
51.1% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
30	1750	14.5	55.4	0.197	---
25	1750	15.2	51.1	0.186	---
20	1750	15.9	45.3	0.174	---
15	1750	16.4	37.4	0.16	---
10	1750	16.9	28.6	0.148	---

DATA POINT
Flow:	25 gpm
Head:	15.2 ft
Efficiency:	51.1%
Power:	0.186 hp
NPSHr:	---
DESIGN CURVE
Shutoff head:	17.3 ft
Shutoff dP:	7.49 psi
Min Flow:	4.2 gpm
BEP:	59.1% @ 42 gpm
NOL Power:	0.215 hp @ 52.1 gpm
MAX CURVE
Max Power:	0.289 hp @ 57.9 gpm

Best Efficiency Point Operation

20 GPM Flow Rate
10.4 FT Head Pressure
51.4% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
24	1750	9.11	53.2	0.103	---
20	1750	10.4	51.4	0.101	---
16	1750	11.3	46.7	0.0966	---
12	1750	12.2	40.2	0.0905	---
8	1750	12.7	30.6	0.0823	---

DATA POINT
Flow:	20 gpm
Head:	10.4 ft
Efficiency:	51.4%
Power:	0.101 hp
NPSHr:	---
DESIGN CURVE
Shutoff head:	13 ft
Shutoff dP:	5.65 psi
Min Flow:	2.57 gpm
BEP:	54% @ 25.7 gpm
NOL Power:	0.103 hp @ 25.7 gpm
MAX CURVE
Max Power:	0.184 hp @ 31.4 gpm

Best Efficiency Point Operation

35 GPM Flow Rate
14 FT Head Pressure
57.1% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
42	1750	12.4	59	0.222	---
35	1750	14	57.4	0.213	---
28	1750	15.2	53.3	0.2	---
21	1750	16.2	46.4	0.183	---
14	1750	17	35.5	0.164	---

DATA POINT
Flow:	35 gpm
Head:	14 ft
Efficiency:	57.4%
Power:	0.213 hp
NPSHr:	---
DESIGN CURVE
Shutoff head:	17.8 ft
Shutoff dP:	7.7 psi
Min Flow:	4.27 gpm
BEP:	59.1% @ 42.7 gpm
NOL Power:	0.224 hp @ 52.9 gpm
MAX CURVE
Max Power:	0.289 hp @ 57.9 gpm

Best Efficiency Point Operation

30 GPM Flow Rate
18.9 FT Head Pressure
50.5% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
36	1750	18.3	54.8	0.303	---
30	1750	18.9	50.5	0.281	---
24	1750	19.5	45.9	0.258	---
18	1750	20	37.9	0.233	---
12	1750	20.5	29.7	0.209	---

DATA POINT
Flow:	30 gpm
Head:	18.9 ft
Efficiency:	50.5%
Power:	0.281 hp
NPSHr:	---
DESIGN CURVE
Shutoff head:	21 ft
Shutoff dP:	9.1 psi
Min Flow:	4.63 gpm
BEP:	58.6% @ 46.3 gpm
NOL Power:	0.364 hp @ 71.2 gpm
MAX CURVE
Max Power:	0.364 hp @ 71.2 gpm

Best Efficiency Point Operation

35 GPM Flow Rate
41.6 FT Head Pressure
55.4% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
42	3550	40.2	59.2	0.708	4.26
35	3550	41.6	55.4	0.663	3.73
28	3550	42.5	48.4	0.603	3.21
21	3550	43.4	41.5	0.544	2.7
14	3550	44.2	29.9	0.513	2.49

DATA POINT
Flow:	35 US gpm
Head:	41.6 ft
Efficiency:	55.4%
Power:	0.663 hp
NPSHr:	3.73 ft
DESIGN CURVE
Shutoff head:	45.6 ft
Shutoff dP:	19.8 psi
Min Flow:	6.87 US gpm
BEP:	66.8% @ 68.7 gpm
NOL Power:	0.86 hp @ 85.6 gp
MAX CURVE
Max Power:	2.21 hp @ 117 gpm

Best Efficiency Point Operation

50 GPM Flow Rate
45.8 FT Head Pressure
61.8% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
60	3550	43.1	65.4	0.99	6.3
50	3550	45.8	61.8	0.924	5.4
40	3550	48.1	56.7	0.85	4.57
30	3550	49.7	48.4	0.756	3.76
20	3550	51.1	39.2	0.656	2.95

DATA POINT
Flow:	50 US gpm
Head:	45.8 ft
Efficiency:	61.8%
Power:	0.924 hp
NPSHr:	5.4 ft
DESIGN CURVE
Shutoff head:	53.3 ft
Shutoff dP:	23.1 psi
Min Flow:	7.37 US gpm
BEP:	66.8% @ 73.7 gpm
NOL Power:	1.08 hp @ 91.7 gpm
MAX CURVE
Max Power:	2.21 hp @ 117 gpm

Best Efficiency Point Operation

60 GPM Flow Rate
52.7 FT Head Pressure
64.5% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
72	3550	48	66.1	1.31	8.23
60	3550	52.7	64.5	1.23	6.91
48	3550	55.6	58.9	1.13	5.82
36	3550	58.1	51.4	1.01	4.74
24	3550	60	41.2	0.867	3.69

DATA POINT
Flow:	60 US gpm
Head:	52.7 ft
Efficiency:	64.5%
Power:	1.23 hp
NPSHr:	6.91 ft
DESIGN CURVE
Shutoff head:	63 ft
Shutoff dP:	27.3 psi
Min Flow:	7.98 US gpm
BEP:	66.8% @ 79.8 gpm
NOL Power:	1.38 hp @ 99.4 gpm
MAX CURVE
Max Power:	2.21 hp @ 117 gpm

Best Efficiency Point Operation

60 GPM Flow Rate
60.1 FT Head Pressure
62.9% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
72	3550	55.8	65.7	1.53	8.71
60	3550	60.1	62.9	1.43	7.4
48	3550	63.2	57.6	1.32	6.25
36	3550	65.6	49.7	1.17	5.12
24	3550	67.6	40	1.01	4

DATA POINT
Flow:	60 gpm
Head:	60.1 ft
Efficiency:	62.9%
Power:	1.43 hp
NPSHr:	7.4 ft
DESIGN CURVE
Shutoff head:	70.7 ft
Shutoff dP:	30.6 psi
Min Flow:	8.47 gpm
BEP:	66.8% @ 84.7 gpm
NOL Power:	1.64 hp @ 105 gpm
MAX CURVE
Max Power:	2.21 hp @ 117 gpm

Best Efficiency Point Operation

70 GPM Flow Rate
73.7 FT Head Pressure
62.2% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
84	3550	69.5	65.3	2.24	12.2
70	3550	73.7	62.2	2.09	10.2
56	3550	76.7	56.4	1.9	8.36
42	3550	79.4	49	1.69	6.61
28	3550	81.4	38.4	1.46	5.04

DATA POINT
Flow:	70 gpm
Head:	73.7 ft
Efficiency:	62.2%
Power:	2.09 hp
NPSHr:	10.2 ft
DESIGN CURVE
Shutoff head:	83.7 ft
Shutoff dP:	36.2 psi
Min Flow:	9.14 gpm
BEP:	67% @ 91.4 gpm
NOL Power:	2.56 hp @ 133 gpm
MAX CURVE
Max Power:	2.83 hp @ 138 gpm

230VAC 50Hz. Single Phase Pumps

Best Efficiency Point Operation

114 LPM Flow Rate
3.41 M Head Pressure
57.1% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
137	1450	3.04	58.7	0.115	n/a
114	1450	3.41	57.1	0.11	n/a
91.2	1450	3.68	52.5	0.103	n/a
68.4	1450	3.9	45.3	0.0945	n/a
45.6	1450	4.08	34.8	0.0848	n/a

DATA POINT
Flow:	114 lpm
Head:	3.41 m
Efficiency:	57.1%
Power:	0.11 kW
NPSHr:	---
DESIGN CURVE
Shutoff head:	4.25 m
Shutoff dP:	41.7 kPa
Min Flow:	14.4 lpm
BEP:	59.1% @ 144 lpm
NOL Power:	0.117 kW @ 179 lpm
MAX CURVE
Max Power:	0.122 kW @ 182 lpm

Best Efficiency Point Operation

114 LPM Flow Rate
5.88 M Head Pressure
53.7% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
136	2950	4.58	51.6	0.192	1.32
114	2950	5.86	53.7	0.199	1.03
90.9	2950	7.02	51.9	0.199	0.845
68.2	2950	7.83	45.7	0.189	0.686
45.4	2950	8.39	35	0.172	0.721

DATA POINT
Flow:	114 lpm
Head:	5.88 m
Efficiency:	53.7%
Power:	0.199 kW
NPSHr:	1.02 m
DESIGN CURVE
Shutoff head:	8.91 m
Shutoff dP:	87.3 kPa
Min Flow:	12.6 lpm
BEP:	54.1% @ 126 lpm
NOL Power:	0.201 kW @ 95.4 lpm
MAX CURVE
Max Power:	0.516 kW @ 131 lpm

Best Efficiency Point Operation

189 LPM Flow Rate
10.9 M Head Pressure
64.9% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
227	2950	9.85	66.2	0.546	1.72
189	2950	10.9	64.8	0.516	1.44
151	2950	11.5	59.1	0.471	1.21
114	2950	12	51.9	0.422	0.99
75.7	2950	12.4	41.4	0.362	0.767

DATA POINT
Flow:	189 lpm
Head:	10.9 m
Efficiency:	64.9%
Power:	0.516 kW
NPSHr:	1.44 m
DESIGN CURVE
Shutoff head:	13 m
Shutoff dP:	128 kPa
Min Flow:	24.9 lpm
BEP:	66.8% @ 249 lpm
NOL Power:	0.573 kW @ 310 lpm
MAX CURVE
Max Power:	0.944 kW @ 369 lpm

Best Efficiency Point Operation

265 LPM Flow Rate
11 M Head Pressure
66.8% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
318	2950	9.52	65.5	0.753	2.79
265	2950	11	66.8	0.707	2.32
212	2950	12	63.6	0.648	1.86
159	2950	12.8	56.9	0.576	1.42
106	2950	13.4	46.1	0.49	1.03

DATA POINT
Flow:	265 lpm
Head:	11 m
Efficiency:	66.8%
Power:	0.707 kW
NPSHr:	2.32 m
DESIGN CURVE
Shutoff head:	14 m
Shutoff dP:	137 kPa
Min Flow:	25.4 lpm
BEP:	67% @ 254 lpm
NOL Power:	0.769 kW @ 370 lpm
MAX CURVE
Max Power:	1.21 kW @ 435 lpm

Best Efficiency Point Operation

265 LPM Flow Rate
12.3 M Head Pressure
66.9% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
318	2950	10.8	66	0.847	2.91
265	2950	12.3	66.9	0.795	2.42
212	2950	13.3	62.8	0.728	1.94
159	2950	14.1	55.8	0.645	1.49
106	2950	14.6	44.8	0.55	1.09

DATA POINT
Flow:	265 lpm
Head:	12.3 m
Efficiency:	66.9%
Power:	0.795 kW
NPSHr:	2.42 m
DESIGN CURVE
Shutoff head:	15.3 m
Shutoff dP:	150 kPa
Min Flow:	26.6 lpm
BEP:	67% @ 266 lpm
NOL Power:	0.878 kW @ 388 lpm
MAX CURVE
Max Power:	1.21 kW @ 435 lpm

Best Efficiency Point Operation

265 LPM Flow Rate
13.7 M Head Pressure
66.1% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
318	2950	11.6	64.5	0.924	2.89
265	2950	13.7	66.1	0.886	2.33
212	2950	15.2	63.3	0.822	1.89
159	2950	16.2	56.5	0.736	1.52
106	2950	16.8	45.2	0.626	1.16

DATA POINT
Flow:	265 lpm
Head:	13.7 mm
Efficiency:	66.1%
Power:	0.886 kW
NPSHr:	2.33 m
DESIGN CURVE
Shutoff head:	17.9 m
Shutoff dP:	175 kPa
Min Flow:	29.5 lpm
BEP:	66.8% @ 295 lpm
NOL Power:	0.936 kW @ 367 lp
MAX CURVE
Max Power:	0.944 kW @ 369 lpm

Best Efficiency Point Operation

265 LPM Flow Rate
15.3 M Head Pressure
65% Peak Efficiency

FLOW GPM	SPEED RPM	HEAD FT	EFF. %	POWER HP	NPSHr FT
318	2950	13.9	66.6	1.08	3.15
265	2950	15.3	65	1.01	2.63
212	2950	16.3	60.8	0.923	2.11
159	2950	17	53.6	0.819	1.64
106	2950	17.6	42.2	0.7	1.22

DATA POINT
Flow:	265 lpm
Head:	15.3 m
Efficiency:	65%
Power:	1.01 kW
NPSHr:	2.63 m
DESIGN CURVE
Shutoff head:	18.3 m
Shutoff dP:	179 kPa
Min Flow:	29.4 lpm
BEP:	67% @ 294 lpm
NOL Power:	1.16 kW @ 428 lpm
MAX CURVE
Max Power:	1.21 kW @ 435 lpm
